Hudson Flanges, a well-established manufacturer and supplier in Midland, UK, is an expert in providing high-quality flanges to serve industrial requirements With proficiency in ANSI/ASA B16.5 flange standards, we provide consistent, durable to fit diverse applications and we provide total engineering solutions. Our extensive collection of flanges, which are offered in a broad range of sizes and materials, provides compatibility and efficiency for mission-critical applications. At Hudson Flanges, competitive pricing, outstanding customer service and timely delivery are our strengths, making us your go-to industry partner.
ANSI/ASA B16.5 flanges are made from materials like carbon steel, stainless steel and steel alloys, which give them durability and resistance to corrosion. Their precise materials contain components like carbon, manganese, silicon, chromium, and nickel, based on the application requirements. Mechanically they provide good strength, yield strength and toughness, which makes them suitable for high temperature and high pressure conditions. Advantages are seamless fit, pressure durability and standardized dimensions for wear and corrosion resistance. These characteristics make them popular for pipeline systems in the oil, gas, chemicals and power generation industries.
| Specifications | ANSI / ASA B16.5 Flanges |
|---|---|
| ANSI / ASA B16.5 Flange size range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Main Types | Forged / Threaded / Screwed / Plate |
| Flange supporting material | Gasket, Ring Joint, Flange Bolts |
| Production technique | Forged, Heat treated and machined |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS JIS Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange |
| Specialized manufacturer of | DIN 2566 en 1092 1 Pn16 Flange DIN 2566 pn16 Rtj Flange ANSI / ASA B16.5 Sorf Flange ANSI / ASA B16.5 Table Flanges DIN 2566 pn10 ANSI / ASA B16.5 Large Diameter Flange ANSI / ASA B16.5 Threaded Flanges ANSI / ASA B16.5 Blind Flanges ANSI / ASA B16.5 Plate Flanges ANSI / ASA B16.5 Weld Neck Flanges ANSI / ASA B16.5 Loose Flanges ANSI / ASA B16.5 Orifice Flanges ANSI / ASA B16.5 Slip-On Flanges ANSI / ASA B16.5 Lap Joint Flanges ANSI / ASA B16.5 Socketweld Flanges ANSI / ASA B16.5 AS 4087 Water Flanges |
| Test | Hydrostatic testing machine, Direct-reading Spectrograph,UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
| Equipment | Bending machine, Press machine, electric bevelling machine, Pushing Machine, Sand-blasting machine etc |
| Origin | West Europe /Indian / USA / Japan / Korean |
| Key markets and industries for ANSI / ASA B16.5 Flange | Nuclear power (mostly seamless). Heavy oil refineries. Bitumen upgraders. Petrochemicals and acids. |
| Export to | Indonesia, Ireland, Ukraine, Singapore,Saudi Arabia,Canada, Peru, Dubai, Brazil, Iran, Korea, USA, India, Egypt, Thailand, Spain, Oman etc |
| ANSI / ASA B16.5 Flanges Application | To Connect Pipe & Tubes in Power, Petroleum,Construction, Chemical, Gas, Shipbuilding,Metallurgy, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Hudson Flanges, a premier supplier in Midland, UK, specializes in high-quality ANSI / ASA B16.5 Flange, valued for their exceptional durability, corrosion resistance, precise engineering, and suitability across diverse industrial applications.
ANSI/ASA B16.5 flanges are crucial elements of piping systems across many industries. They are employed to join pipes, valves, pumps and other devices, providing secure, watertight connections. They are commonly used in oil and gas, chemical processing, power generation, and water treatment, and perform well under high pressures and high temperatures They are used for tangling, cracking and repairing pipes. Their general design provides compatibility with a vast array of pipeline components, thus making them necessary for efficient and safe water and gas transport systems.
ANSI/ASME/ASA B16.5 300lb/sq.in. Flange BLIND-RF | |||||||
ø | D | b | g | k | Holes | l | Kg. |
1/2″ | 95,2 | 14,3 | 34,9 | 66,7 | 4 | 15,9 | 0,700 |
3/4″ | 117,5 | 15,9 | 42,9 | 82,5 | 4 | 19,0 | 1,200 |
1″ | 123,8 | 17,5 | 50,8 | 88,9 | 4 | 19,0 | 1,500 |
1 1/4″ | 133,3 | 19,0 | 63,5 | 98,4 | 4 | 19,0 | 2,000 |
1 1/2″ | 155,6 | 20,6 | 73,0 | 114,3 | 4 | 22,2 | 2,900 |
2″ | 165,1 | 22,2 | 92,1 | 127,0 | 8 | 19,0 | 3,400 |
2 1/2″ | 190,5 | 25,4 | 104,8 | 149,2 | 8 | 22,2 | 5,100 |
3″ | 209,5 | 28,6 | 127,0 | 168,3 | 8 | 22,2 | 7,000 |
3 1/2″ | 228,6 | 30,2 | 139,7 | 184,1 | 8 | 22,2 | 8,900 |
4″ | 254,0 | 31,7 | 157,2 | 200,0 | 8 | 22,2 | 11,800 |
5″ | 279,4 | 34,9 | 185,7 | 234,9 | 8 | 22,2 | 15,500 |
6″ | 317,5 | 36,5 | 215,9 | 269,9 | 12 | 22,2 | 21,300 |
8″ | 381,0 | 41,3 | 269,9 | 330,2 | 12 | 25,4 | 35,200 |
10″ | 444,5 | 47,6 | 323,8 | 387,3 | 16 | 28,6 | 57,000 |
12″ | 520,7 | 50,8 | 381,0 | 450,8 | 16 | 31,7 | 82,000 |
14″ | 584,2 | 54,0 | 412,7 | 514,3 | 20 | 31,7 | 106,000 |
16″ | 647,7 | 57,1 | 469,9 | 571,5 | 20 | 34,9 | 140,000 |
18″ | 711,2 | 60,3 | 533,4 | 628,6 | 24 | 34,9 | 178,000 |
20″ | 774,7 | 63,5 | 584,2 | 685,8 | 24 | 34,9 | 223,000 |
22″ | 838,2 | 66,7 | 641,2 | 742,9 | 24 | 41,3 | 270,000 |
24″ | 914,4 | 69,8 | 692,1 | 812,8 | 24 | 41,3 | 345,000 |
Yes, we offer custom sizes for ANSI / ASA B16.5 Flange to meet specific project needs. Our team at Hudson Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@hudsonflanges.co.uk.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
