Hudson Flanges, located in Midland, UK, is a renowned manufacturer and supplier of high-quality Australian flanges. Designed for diverse industrial applications, Australian flanges are known for their durability, precision, and resistance to extreme conditions. Ideal for industries like oil and gas, petrochemicals, and power generation, our Australian flanges provide secure, leak-proof connections in critical piping systems. Hudson Flanges ensures that every Australian flange meets the highest industry standards for performance, reliability, and longevity, delivering cost-effective solutions for all your flange needs.
Australian flanges are typically made from high-strength materials like carbon steel, stainless steel, and alloy steels, providing excellent resistance to corrosion, wear, and high-temperature environments. They are designed to withstand the stresses of various industrial applications, including oil and gas, chemical, and power generation. The mechanical properties include high tensile strength, toughness, and fatigue resistance. The advantages of Australian flanges include easy installation, leak-proof sealing, long-lasting durability, and resistance to harsh environments. These flanges ensure reliable connections in piping systems, providing both performance and cost-efficiency in demanding operations.
| Material Specification Of : | Australian Flange And Sabs 1123 Pipe Flanges |
|---|---|
| Standard Cover : | pressure ratings & temperature ratings, materials, marking, dimensions, weight, tolerances, testing |
| Contact Faces | RTJ (Ring Type Joint), FF (Flat Face), RF (Raised Face), T/G (Tongue And Groove ), M/F (Male And Female) |
| Marking Standard | Name of Manufacturer Schedule Type of Flange Facing Nominal Pipe Size Pressure Class ASME B16 Designation |
| Bolt Type | high strength bolts medium strength bolts low strength bolts |
| Surface Finish | smooth, concentric serrated, stock |
| Gaskets Types | Full Face Gasket Flat Ring Gasket Metallic Ring Gakset |
| Advantages Of Pipe Flange | Used to Connect Pipe System Easy Repair Pipe System Assembled Without Welding |
| Size Chart | Normal Pipe Size 1/2 to NPS 24″ |
| Materials | Stainless Steel (Grade 304/L, 316/L), Carbon Steel (ASTM A105 And ASTM A350), Alloy Steel (ASTM A182), Mild Steel, Duplex Steel, Pressure Vessel Steel, Titanium, Super Duplex Steel, Nickel Alloy, Monel, Inconel, Hastelloy, Copper Nickel, Cast Iron, Wrought Iron. |
| Thickness | Normal Pipe Size ≤ 18 |
| Bore Diameter | Normal Pipe ≤ 10 |
| Flanges Standards | EN 1092-1, JIS, ASME B16.5, ASME B16.47 type A, UNI, DIN |
| Pressure Rating | Class 150 To Class 2500 |
| High Temperature | Above 200°C (400°F) For Class 150 Or Above 400°C (750°F) |
| Low Temperature | Above -29 Degree C (−20°F) |
| Common Types Of Flanges: | Slip On (SORF), Weld Neck (WNRF), Blind (BLRF), Lap Joint (Loose), Threaded (NPT), Socket-Weld (SWRF) |
| Special Types Of Flanges : | Nipoflange, Elboflange, Latroflange, Swivel Flange, Expanding Flange, Reducing Flange, Weldoflange |
|
Nominal Pipe Bore 15 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600/3 |
80millimeter |
55millimeter |
4 |
M10 |
11millimeter |
10millimeter |
|
SABS1123-1000/3 |
95millimeter |
65millimeter |
4 |
M12 |
14millimeter |
10millimeter |
|
SABS1123-1600/3 |
95millimeter |
65millimeter |
4 |
M12 |
14millimeter |
10millimeter |
|
SABS1123-2500/3 |
95millimeter |
65millimeter |
4 |
M12 |
14millimeter |
14millimeter |
|
SABS1123-4000/3 |
95millimeter |
65millimeter |
4 |
M12 |
14millimeter |
14millimeter |
|
Nominal Pipe Bore 20 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
90millimeter |
65millimeter |
4 |
M10 |
11millimeter |
10millimeter |
|
SABS1123-1000 |
105millimeter |
75millimeter |
4 |
M12 |
14millimeter |
10millimeter |
|
SABS1123-1600 |
105millimeter |
75millimeter |
4 |
M12 |
14millimeter |
10millimeter |
|
SABS1123-2500 |
105millimeter |
75millimeter |
4 |
M12 |
14millimeter |
14millimeter |
|
SABS1123-4000 |
105millimeter |
75millimeter |
4 |
M12 |
14millimeter |
14millimeter |
|
Nominal Pipe Bore 25 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
100millimeter |
75millimeter |
4 |
M10 |
11millimeter |
10millimeter |
|
SABS1123-1000 |
115millimeter |
85millimeter |
4 |
M12 |
14millimeter |
10millimeter |
|
SABS1123-1600 |
115millimeter |
85millimeter |
4 |
M12 |
14millimeter |
10millimeter |
|
SABS1123-2500 |
115millimeter |
85millimeter |
4 |
M12 |
14millimeter |
16millimeter |
|
SABS1123-4000 |
115millimeter |
85millimeter |
4 |
M12 |
14millimeter |
16millimeter |
|
Nominal Pipe Bore 32 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
120millimeter |
90mm |
4 |
M12 |
14mm |
10mm |
|
SABS1123-1000 |
140mm |
100mm |
4 |
M16 |
18mm |
10mm |
|
SABS1123-1600 |
140mm |
100mm |
4 |
M16 |
18mm |
10mm |
|
SABS1123-2500 |
140mm |
100mm |
4 |
M16 |
18mm |
18mm |
|
SABS1123-4000 |
140mm |
100mm |
4 |
M16 |
18mm |
18mm |
|
Nominal Pipe Bore 40 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
130mm |
100mm |
4 |
M12 |
14mm |
10mm |
|
SABS1123-1000 |
150mm |
110mm |
4 |
M16 |
18mm |
10mm |
|
SABS1123-1600 |
150mm |
110mm |
4 |
M16 |
18mm |
10mm |
|
SABS1123-2500 |
150mm |
110mm |
4 |
M16 |
18mm |
20mm |
|
SABS1123-4000 |
150mm |
110mm |
4 |
M16 |
18mm |
20mm |
|
Nominal Pipe Bore 50 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
140mm |
110mm |
4 |
M12 |
14mm |
10mm |
|
SABS1123-1000 |
165mm |
125mm |
4 |
M16 |
18mm |
10mm |
|
SABS1123-1600 |
165mm |
125mm |
4 |
M16 |
18mm |
12mm |
|
SABS1123-2500 |
165mm |
125mm |
4 |
M16 |
18mm |
20mm |
|
SABS1123-4000 |
165mm |
125mm |
4 |
M16 |
18mm |
20mm |
|
Nominal Pipe Bore 65 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
160mm |
130mm |
4 |
M12 |
14mm |
10mm |
|
SABS1123-1000 |
185mm |
145mm |
4 |
M16 |
18mm |
12mm |
|
SABS1123-1600 |
185mm |
145mm |
4 |
M16 |
18mm |
12mm |
|
SABS1123-2500 |
185mm |
145mm |
8 |
M16 |
18mm |
22mm |
|
SABS1123-4000 |
185mm |
145mm |
8 |
M16 |
18mm |
22mm |
|
Nominal Pipe Bore 80 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
190mm |
150mm |
4 |
M16 |
18mm |
10mm |
|
SABS1123-1000 |
200mm |
160mm |
8 |
M16 |
18mm |
12mm |
|
SABS1123-1600 |
200mm |
160mm |
8 |
M16 |
18mm |
14mm |
|
SABS1123-2500 |
200mm |
160mm |
8 |
M16 |
18mm |
22mm |
|
SABS1123-4000 |
200millimeter |
160millimeter |
8 |
M16 |
18millimeter |
22millimeter |
|
Nominal Pipe Bore100 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
210millimeter |
170millimeter |
4 |
M16 |
18millimeter |
10millimeter |
|
SABS1123-1000 |
220millimeter |
180millimeter |
8 |
M16 |
18millimeter |
12millimeter |
|
SABS1123-1600 |
220millimeter |
180millimeter |
8 |
M16 |
18millimeter |
14millimeter |
|
SABS1123-2500 |
235millimeter |
190millimeter |
8 |
M20 |
22millimeter |
25millimeter |
|
SABS1123-4000 |
235millimeter |
190millimeter |
8 |
M20 |
22millimeter |
25millimeter |
|
Nominal Pipe Bore150 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
240millimeter |
200millimeter |
8 |
M16 |
18millimeter |
12millimeter |
|
SABS1123-1000 |
250millimeter |
210millimeter |
8 |
M16 |
18millimeter |
14millimeter |
|
SABS1123-1600 |
250millimeter |
210millimeter |
8 |
M16 |
18millimeter |
16millimeter |
|
SABS1123-2500 |
270millimeter |
220millimeter |
8 |
M24 |
26millimeter |
28millimeter |
|
SABS1123-4000 |
270millimeter |
220millimeter |
8 |
M24 |
26mm |
28mm |
|
Nominal Pipe Bore200 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
265mm |
225mm |
8 |
M16 |
18mm |
12mm |
|
SABS1123-1000 |
285mm |
240mm |
8 |
M20 |
22mm |
16mm |
|
SABS1123-1600 |
285mm |
240mm |
8 |
M20 |
22mm |
18mm |
|
SABS1123-2500 |
300mm |
250mm |
8 |
M24 |
26mm |
30mm |
|
SABS1123-4000 |
300mm |
250mm |
8 |
M24 |
26mm |
30mm |
|
Nominal Pipe Bore250 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
320mm |
280mm |
8 |
M16 |
18mm |
14mm |
|
SABS1123-1000 |
340mm |
295mm |
8 |
M20 |
22mm |
18mm |
|
SABS1123-1600 |
340mm |
295mm |
12 |
M20 |
22mm |
22mm |
|
SABS1123-2500 |
360mm |
310mm |
12 |
M24 |
26mm |
28mm |
|
SABS1123-4000 |
375mm |
320mm |
12 |
M24 |
26mm |
32mm |
|
Nominal Pipe Bore300 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
375mm |
335mm |
12 |
M16 |
18mm |
16mm |
|
SABS1123-1000 |
395mm |
350mm |
12 |
M20 |
22mm |
20mm |
|
SABS1123-1600 |
405mm |
355mm |
12 |
M24 |
26mm |
25mm |
|
SABS1123-2500 |
425mm |
370mm |
12 |
M24 |
26mm |
30mm |
|
SABS1123-4000 |
450mm |
385mm |
12 |
M30 |
33mm |
38mm |
|
Nominal Pipe Bore500 |
Diameter Of Flange |
PCD |
Bolts Of Flanges |
Size Of Bolt |
Size Of Hole |
Thickness Of Flanges |
|
SABS1123-600 |
645mm |
600mm |
20 |
M20 |
22mm |
25mm |
|
SABS1123-1000 |
670mm |
620mm |
20 |
M24 |
26mm |
32mm |
|
SABS1123-1600 |
715mm |
650mm |
20 |
M30 |
33mm |
40mm |
|
SABS1123-2500 |
730mm |
660mm |
20 |
M30 |
33mm |
50mm |
|
SABS1123-4000 |
755mm |
670mm |
20 |
M39 |
39mm |
70mm |
Hudson Flanges, a leading supplier in Midland, UK, offers an extensive selection of Australian Flange, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Australian flanges are widely used in industries such as oil and gas, petrochemical, power generation, and water treatment. They provide reliable, leak-proof connections in piping systems, making them ideal for high-pressure and high-temperature applications. These flanges are used to connect pipes, valves, pumps, and other components in critical infrastructure, ensuring the safe and efficient transportation of fluids, gases, and steam. Their durability and resistance to corrosion and extreme conditions make them essential for industries that require long-lasting, secure connections in harsh environments.
Yes, we offer custom sizes for Australian Flange to meet specific project needs. Our team at Hudson Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@hudsonflanges.co.uk.
| Standard Of Flanges | Class Of Flanges | Diameter Of Flanges | Bolt Circle Diameter Of Flanges | Flanges Number of Bolts | Flanges Bolt Size | Flanges Diameter of Bolt Hole |
|---|---|---|---|---|---|---|
| AS4087 Flanges | PN14 Flanges | 95 | 67 | 4 | M12 | 14 |
| AS 2129 Flange | Table C Flanges | 95 | 67 | 4 | 13 | 14 |
| Table D Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table E Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table F Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table H Flanges | 114 | 83 | 4 | 16 | 17 | |
| Table J Flanges | 114 | 83 | 4 | 16 | 17 | |
| ANSI B16.5 Flanges | ANSI 150 Flanges | 89 | 60 | 4 | 13 | 16 |
| ANSI 300 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 600 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 900 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ANSI 1500 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ISO 7005 (DIN) Flange | PN6 Flanges | 80 | 55 | 4 | M10 | 11 |
| PN10 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN16 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN20 Flanges | 90 | 60.5 | 4 | M14 | 16 | |
| PN25 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN40 Flanges | 95 | 65 | 4 | M12 | 14 |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
