Hudson Flanges, a leading manufacturer and supplier based in Midland, UK, specializes in high-quality DIN 2565 PN6 Threaded Flanges for low-pressure applications. These threaded flanges are designed for easy installation without the need for welding, making them ideal for systems that require frequent maintenance or adjustments. Commonly used in water treatment, construction, and light industrial applications, Hudson’s DIN 2565 PN6 Threaded Flanges ensure secure connections and system integrity. Hudson Flanges is dedicated to providing reliable, precision-engineered solutions for diverse industry needs.
DIN 2565 PN6 Threaded Flanges are typically made from high-quality carbon steel, stainless steel, or alloy steel, providing good corrosion resistance and durability for low-pressure systems. These flanges feature a threaded design, enabling easy installation without welding, which makes them ideal for applications where disassembly is needed. They offer moderate tensile strength and stability, suitable for low-pressure environments. Key advantages include convenient installation, cost-effectiveness, and minimal maintenance requirements. DIN 2565 PN6 Threaded Flanges are widely used in water treatment, construction, and light industrial applications, ensuring secure, leak-proof connections.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | D | b | k | h1 | d3 | d4 | f | Holes | Thread | d2 | Kg | |
| 15 | 21,3 | R 1/2 | 80 | 12 | 55 | 20 | 30 | 40 | 2 | 4 | M 10 | 11 | 0,373 |
| 20 | 26,9 | R 3/4 | 90 | 14 | 65 | 24 | 40 | 50 | 2 | 4 | M 10 | 11 | 0,59 |
| 25 | 33,7 | R 1 | 100 | 14 | 75 | 24 | 50 | 60 | 2 | 4 | M 10 | 11 | 0,743 |
| 32 | 42,4 | R 1 1/4 | 120 | 14 | 90 | 26 | 60 | 70 | 2 | 4 | M 12 | 14 | 1,05 |
| 40 | 48,3 | R 1 1/2 | 130 | 14 | 100 | 26 | 70 | 80 | 3 | 4 | M 12 | 14 | 1,2 |
| 50 | 60,3 | R 2 | 140 | 14 | 110 | 28 | 80 | 90 | 3 | 4 | M 12 | 14 | 1,37 |
| 65 | 76,1 | R 2 1/2 | 160 | 14 | 130 | 32 | 100 | 110 | 3 | 4 | M 12 | 14 | 1,92 |
| 80 | 88,9 | R 3 | 190 | 16 | 150 | 34 | 110 | 128 | 3 | 4 | M 16 | 18 | 2,82 |
| 100 | 114,3 | R 4 | 210 | 16 | 170 | 38 | 130 | 148 | 3 | 4 | M 16 | 18 | 3,19 |
| 125 | 139,7 | R 5 | 240 | 18 | 200 | 40 | 160 | 178 | 3 | 8 | M 16 | 18 | 4,47 |
| 150 | 165,1 | R 6 | 265 | 18 | 225 | 44 | 185 | 202 | 3 | 8 | M 16 | 18 | 5,3 |
Hudson Flanges, a leading supplier in Midland, UK, offers an extensive selection of DIN 2565 PN6 Threaded Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2565 PN6 Threaded Flanges are commonly used in low-pressure systems where frequent disassembly or maintenance is required. They are ideal for water treatment facilities, construction projects, and light industrial applications, as they can be easily screwed into place without the need for welding. These flanges securely connect pipes and equipment, ensuring leak-free performance and straightforward installation. Their versatility and ease of use make them suitable for applications involving non-corrosive fluids, where a reliable, cost-effective, and easy-to-maintain connection is essential.
Yes, we offer custom sizes for DIN 2565 PN6 Threaded Flanges to meet specific project needs. Our team at Hudson Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@hudsonflanges.co.uk.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2565 PN6 Threaded Flanges Supplier in Midland | Alloy Steel DIN 2565 PN6 Threaded Flanges Manufacturer in UK |
| DIN 2565 PN6 Screwed Flange Stockist in UK | Raised Faced DIN 2565 PN6 Slip-On flanges Dealer in United Kingdom |
| ASME SA105N Raised Faced DIN 2565 PN6 Threaded Flanges | 18 inch Carbon Steel DIN 2565 PN6 Threaded Flange |
| Stainless Steel DIN 2565 PN6 Threaded Flange | ASTM B564 Raised Faced DIN 2565 PN6 Threaded Flanges |
| Carbon Steel Raised Face DIN 2565 PN6 Screwed Flange Stockist | Duplex Steel DIN 2565 PN6 Threaded Flanges Supplier in mm |
| DIN 2565 PN6 Threaded Flange Dimensions | Raised Face DIN 2565 PN6 Threaded Flange Manufacturer |
| Carbon Steel DIN 2565 PN6 Threaded Flange | DIN 2565 PN6 Threaded RF Flange Supplier |
| DIN 2565 PN6 Threaded Flanges Distributor in Liversedge | Flat Face DIN 2565 PN6 Threaded Flanges Exporter |
| DIN 2565 PN6 Threaded Flange Manufacturer | Flat Face DIN 2565 PN6 Screwed Flange Manufacturer |
| 30 inch DIN 2565 PN6 Threaded Flange Dealer | Raised Face DIN 2565 PN6 Threaded Flanges Manufacturer |
| 18 inch DIN 2565 PN6 Carbon Steel Threaded Flange | DIN 2565 PN6 Threaded Flange Dimensions in mm |
| 8 Inch DIN 2565 PN6 Threaded Pipe Flanges | DIN 2565 PN6 Threaded Flanges Stockist |
| Alloy Steel DIN 2565 PN6 Threaded Flanges | Copper Nickel DIN 2565 PN6 Threaded Flanges at Best Price |
| Nickel Alloy DIN 2565 PN6 Threaded Flange | Mild Steel DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Screwed Flanges Supplier in West Midland | MS DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Threaded Flange Exporter | DIN 2565 PN6 Threaded Flange Pressure Ratings |
| DIN 2565 PN6 Large Diameter Threaded Flange | 30 Inch DIN 2565 PN6 Threaded Pipe Flange Dimensions |
| Raised Face DIN 2565 PN6 Threaded Plate Flanges | Titanium DIN 2565 PN6 Threaded Flanges |
| 4 inch Stainless Steel DIN 2565 PN6 Threaded Flange | DIN 2565 PN6 Screwed RF Flanges Stockholder |
| DIN 2565 PN6 Threaded FF Flange Supplier | Suppliers of DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Threaded Pipe Flanges Supplier in Birmingham | Duplex Steel DIN 2565 PN6 Threaded Flanges |
| German Standard DIN 2565 PN6 Threaded Flanges | DIN 2565 PN6 Threaded Flange Supplier in UK |
| DIN 2565 PN6 Threaded Pipe Flanges Wholesaler | DIN 2565 PN6 Threaded Flanges Supplier |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
